RF Matrix Coaxial Switch Matrix
Standard RF Matrix 2X8,2X16,2X32,4X32
Customer Design RF Matrix
Frequency Range DC-6/12.4/18/26.5/40/50/67GHZ
Control Interface RS232,USB,LAN,GPIB etc
Coaxial switch Reflective and Absorptive
- No Part number Type Channels Frequency range RF Connector Datasheet
- 1 2X12 Reflective/Absorptive 2x12 DC-12.4/18/26.5/40GHZ SMA/K(2.92mm) female PDF
- 2 2X16 Reflective/Absorptive 2x16 DC-12.4/18/26.5/40GHZ SMA/K(2.92mm) female PDF
- 3 4x32 Reflective 4x32 DC-12.75GHZ SMA PDF
- 4 1X16 Absorptive 16 DC-18GHZ SMA PDF
- 5 1X32 Absorptive 32 DC-18GHZ SMA PDF
- 6 2xSP20T Reflective 2X20 DC-12.4GHZ SMA PDF
- 7 2XSP32T Reflective 2X32 DC-12.4GHZ SMA PDF
